naturbo interior insulation board
The naturbo interior insulation was specially developed for indoor thermal insulation. Please note our information at the end of this page.
Order number
| Board type | Item number |
|---|---|
| naturbo interior insulation | 1001-14 |
Description
- Vapour diffusion-open interior insulation panel with clay plaster coating for dry construction
- 60 mm wood soft fibre board (DIN EN 13171)
- 10 mm clay plaster on front side with glass fabric for reinforcement
- Flat edge all around
Scope of application
For planking the inside of external walls, also in damp rooms (bath, shower, toilet) except in the immediate splash water area
Technical data
| Dimensions | |
|---|---|
| length | 115 cm |
| width | 64 cm |
| height | 7 cm |
| weight | 20 kg/plate (= 27.2 kg/m²) |
| dimensions | 0.736 m² |
| Structural-physical data | ||
|---|---|---|
| water vapour diffusion resistance | μges < 7 | |
| density | 388 kg/m³ (average) | |
| thermal conductivity | clay plaster front side 10 mm: | λ = 0,76 W/(m•K) |
| Wood soft fibre board 60 mm: | λRated value = 0.042 W/(m•K) |
Data sheet – PDF download
Miscellaneous
| Storage | horizontal, flat, dry |
| Sales units | piece |
The naturbo interior insulation is part of the naturbo interior insulation system in dry construction. To use it you need other products from the naturbo range.
Important note
Despite the naturbo system's generally high tolerance to fluctuations in heat and cold at different levels of humidity, we as manufacturers must point out the following points:
- Individual cases may vary
What generally appears to be harmless, can nevertheless lead to problems in specific individual cases. As manufacturer of the naturbo interior insulation system we do not know your building site. Therefore we cannot assume any liability that the naturbo interior insulation system is a suitable solution in your special individual case. - Specialist
For this reason, we strongly recommend that the interior insulation is carried out with professional, expert advice. It is the task of the expert to assess the building structure, including the condition of the façade, from the point of view of building physics, and on this basis to determine the structure of the interior insulation. - Careful processing
Furthermore, the careful processing of the naturbo interior insulation system is crucial to ensure that no problems arise later. In particular, the ground connection between panels and wall, the full-surface installation of the interior insulation and the avoidance of cold bridges through flank insulation must be taken into account. Exceptions must be assessed by a specialist. - Ventilation
In order to prevent damage later, it is also recommended that rooms with naturbo interior insulation are ventilated regularly and sensibly. Severe deficiencies in ventilation can at some point lead to problems or even damage, even with naturbo interior insulation system.
Ultimately, every tradesman or building owner must decide for themselves who plans the interior insulation and who carries it out. We would just like to emphasize that we as manufacturer cannot take any responsibility for professional planning and professional installation.
